PPGI Sheet

PPGI Sheet, also known as: color compression tile, is the use of color coated steel plate, rolled cold bending into various wave patterns of the compression plate. It is suitable for industrial and civil buildings, warehouses, special buildings, large-span steel structure of the roof, wall and interior and exterior wall decoration, with light weight, high strength, rich color, convenient construction, seismic, fire, rain, long life, maintenance-free and other characteristics, has been widely used.

Category:

PPGI Roof

Keywords:

PPGI Sheet

admin@jinzhemetal.com

+86 18765812635

Product Description

PPGI Sheet, also known as: color compression tile, is the use of color coated steel plate, rolled cold bending into various wave patterns of the compression plate.

It is suitable for industrial and civil buildings, warehouses, special buildings, large-span steel structure of the roof, wall and interior and exterior wall decoration, with light weight, high strength, rich color, convenient construction, seismic, fire, rain, long life, maintenance-free and other characteristics, has been widely used.

1. Light weight: 10-14 kg/square meter, equivalent to 1/30 of the brick wall.

⒉ Thermal conductivity: λ<=0.041w/mk.

C. High strength: can be used for ceiling enclosure plate bearing, bending and compressive resistance; General houses do not use beams and columns.

Bright color: no need for surface decoration, color galvanized steel anti-corrosion layer retention period of 10-15 years.

The installation is flexible and fast: the construction period can be shortened by more than 40%.

Product Parameter

Thickness	0.12mm-0.8mm
Width	600~1150mm
Length	1000-11800mm
Grade	DX51D+Z DX52D+Z DX53D+Z DX54D+Z DX56D+Z DX57D+Z	CS A CS B CS C FS A FS B	SGCC SGCD	SGC340 SGC400 SGC440 SGC490 SGC510	S220GD+Z S250GD+Z S280GD+Z S320GD+Z S350GD+Z S550GD+Z
Zn Coating	Z30-Z275
Color	According to RAL code
Coating Types	PE, SMP, JD, HDP, PVDF
Coating	Top Paint: 10~25 micron
	Back Paint: 5~12micron
Type of coating process	Front: Double Coated & Double Drying
	Back: Double Coated & Double Drying, Single Coated & Double Drying
Finish	High light, Glossy, Matte
Packing	Standard export package (Plastic film in the first layer, second layer is Kraft paper. Third layer is galvanized sheet+package strip+corner protected, one pallet about 3 tons)
Application	Building industry ,structural use, roofing, commercial use ,household appliance, industry facilities, office buildings
Advantages	1.Design according to customers 'requirements 2.Production under ISO9001-2008 Quality System 3.Easy to be installed as light weight 4.Our products are recyclable materials 5.The less construction period, the more using time. 6.paint your logo for free
